Attribute
|
Value | Test Method |
|
Colour
|
Grey | Visual |
|
Thickness（mm）
|
0.4-5.0 | ASTM D374 |
|
Density (g/cc)
|
3.3 | ASTM D792 |
|
Hardness (shore oo)
|
75 | ASTM D2240 |
|
Usage Temperature (C)
|
-60~+200 | - |
|
Flammability
|
V-0 | UL 94 |
|
Electrical
|
||
|
Breakdown Voltage (kV/mm)
|
>6.0 | ASTM D149 |
|
Dielectric Constant @1MHz
|
6.0 | ASTM D150 |
|
Volume Resistivity (Ω.cm)
|
10^12 | ASTM D257 |
|
Thermal
|
||
|
Thermal Conductivity (W/m.K)
|
10.0 | ASTM D5470 |
Legal Disclaimer
The technical information and data shown on this page should be considered representative or typical only and should not be used for specification purposes. Please contact us for more information.
200x400mm or custom die cut parts.
Thickness available in 0.25mm increments.
Store in a cool, dry, well-ventilated place.
Shelf life of the product is 12 months after date of shipment.
